BV4180 PREM/PREMNET
BALERS
Call for Pricing
Special Offers
Stand Alone Financing Installment Program
Implement Stand Alone Financing
Customer instant rebate for Farmer Veteran Coalition members.
Farmer Veteran Coalition Rebate
Up to 0% A.P.R. for 48 Months plus $2,500 Loyalty Cash* on your new Kubota BV Series!
BALER SERIES
Specifications
1 1/4" Main Drive Chain
Bale Formation
Bale Ramp
Bale Width In.
Binding
Cam Clutch Protection
Diameter Max In.
Diameter Min In.
Driveline Chain
Flare To Flare Pickup
Focus Terminal
Fork Feeder
Height In.
Hydraulic Outlets
I S O B U S
Iso Match Tellus
Length In.
Lift
Lift Protection
Minimum P T O Horsepower Required H P/ K W
Monitor
Number Of Tine Rows
P T O Protection
P T O Rpm
Pneumatic Gauge Wheel
Protection, Cam Clutch
Shear Bolt Protection
Tine Spacing In.
Tine To Tine Pickup
Twine
Types Of Belts
Weight Lbs. (kg)
Wheels And Axles | 19.0/45-17
Wheels And Axles | 31x13.5-15
Wide Angle P T O Shaft
Width In.
Windguard
Working Width In.
1 1/4" Main Drive Chain
Standard
Bale Formation
5 Belts + 3 Rollers
Bale Ramp
Standard
Bale Width In.
47" (1.2)
Binding
Net/Twine
Cam Clutch Protection
Standard
Diameter Max In.
71" (1.8)
Diameter Min In.
31" (.8)
Driveline Chain
100
Flare To Flare Pickup
79
Focus Terminal
Standard
Fork Feeder
Standard
Height In.
112" (2.8)
Hydraulic Outlets
1SA + 1DA
I S O B U S
Optional
Iso Match Tellus
Optional
Length In.
176" (4.5)
Lift
Hydraulic
Lift Protection
Radial Clutch
Minimum P T O Horsepower Required H P/ K W
40 - 60
Monitor
Focus
Number Of Tine Rows
112
P T O Protection
Slip clutch
P T O Rpm
Wide angle / 540
Pneumatic Gauge Wheel
Standard
Protection, Cam Clutch
Standard
Shear Bolt Protection
Standard
Tine Spacing In.
2.36"
Tine To Tine Pickup
65
Twine
Double arm / N/A
Types Of Belts
Mato Plate
Weight Lbs. (kg)
5752-5952 (2609-2700)
Wheels And Axles | 19.0/45-17
Optional
Wheels And Axles | 31x13.5-15
Standard
Wide Angle P T O Shaft
Standard
Width In.
99" (2.5)
Windguard
Crop deflector
Working Width In.
79"
